Samsung QM32R-T 32" touch 1920x1080 400 HDMI 2.0 (2) prevádzka 24/7


Samsung QM32R-T 32
Kód tovaru:1009060
Výrobca:Samsung
PN kód:LH32QMRTBGCXEN
EAN kód:
Záruka: 36 mesiacov
Dostupnosť:

skladom (1)

Na dobierku:Nie je možné objednať na dobierku
1471,51€ 1226,26€ bez DPH

Features
All-in-one touch solution for any environment
QMR-T displays maximize the touch display experience with a built-in, high performance Tizen-based media player. The all-in-one design eliminates the need for an external media player and an upgraded Tizen OS makes it easier than ever to utilize various touch apps.

Powerful touch experience
Upgraded Tizen OS makes playback more stable and opens up new possibilities with high-speed content. A responsive capacitive touch functionality offers an engaging user experience and the user-friendly design enables comfortable, productive digital interaction.

Better visibility even in sunlight
SThe QMR-T series offers improved visibility through non-glare glass which removes reflections that might disturb customer engagement, while the haze coating creates a smoother touch.

Built to be reliable and efficient
With an IP5X rating standard, the display is guaranteed to be efficient and reliable even in dusty environments. An innovative center IR means businesses implementing the display, won’t have to make any adjustments and a conformal coating protects the display from repeated customer interactions.

Integrated content and device management solution
Samsung’s MagicINFO solution enables easy content creation for touch display and simple scheduling and management from a selection of curated images and videos. An early warning alert system ensures no downtime.

Panel
Diagonal Size
32"

Type
Edge LED BLU
Resolution
1920*1080 (Full HD)

Pixel Pitch(mm)
0.3638 x0.3638
Active Display Area(mm)
698.4(H) x 392.85(V)
Brightness(Typ.)
300 (with Touch glass), 400(without Touch Glass) nit

Contrast Ratio
5,000:1 (Without Glass)

Viewing Angle(H/V)
178/178

Response Time(G-to-G)
8ms(Typ.)
Display Colors
16.7M
Color Gamut
72%
Operation Hour
16/7

Haze
2% (Without Glass)
Display
Dynamic C/R
MEGA
H-Scanning Frequency
30 ~ 81kHZ
V-Scanning Frequency
48 ~ 75HZ
Maximum Pixel Frequency
594MHz
Sound
Speaker Type
Built in Speaker(10W + 10W)
Connectivity
Input
RGB
Display Port 1.2 (1)
Video
HDMI 2.0 (2)

HDCP
HDCP2.2
Audio
HDMI
USB
USB 2.0 x 2
Output
RGB
HDMI 2.0 (Loop-out)
Audio
Stereo mini Jack
Usb
USB Type-B x 2 (Touch Sensor Data, PC 1 / SoC 1)
External Control
RS232C(in/out) thru stereo jack, RJ45

External Sensor
IR
Power
Type
Internal
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Max[W/h]
72

Typical[W/h]
45

Rating[W/h]
65
BTU(Max)
245.7
Sleep mode
05
Mechanical Specification
Dimension (mm)
Set
744.4 x 444.6 x 48.2
Package
872 x 565 x 133
Weight (kg)
Set
8.3
Package
11.1
VESA Mount (mm)
200 X 200
Stand Type
Foot Stand (Optional)
Bezel Width (mm)
24.5mm(U/D), 21.5mm(L/R)
Operation
Operating Temperature
0 ? ~ 40 ?

Humidity
10 % ~ 80 %
Feature
Key Features
FHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0, Cap touch
Special Features
H/W: Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), Video Wall Daisy Chain(HDCP2.2:4EA,HDCP1.4:7EA), IP5x Rating, Wi-Fi/BT S/W : Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)
Internal Player
Processor
Cortex A72 1.7GHz Quad-Core CPU

On-Chip Cache Memory
L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB

Clock Speed
1.7GHz

Main Memory Interface
2.5GB LPDDR4 1.5GHz 64bit
Graphics
Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.)

Storage (FDM)
8GB (3.88GB Occupied by O/S, 4.12GB Available)

Multimedia
*Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG

IO Ports
USB 2.0
Operating System
Tizen 4.0 (VDLinux)
Certification
Safety
60950-1

EMC
Class B

Security
802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP
Accessory
Included
Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional
Stand
STN-L3240E

Mount
WMN4070SE

Specialty
CML400XK
Media Player
Media Player
Media Player
N/A
