Ubiquiti UniFi 7 PRO, Access Point with 6 GHz support, 2.5 GbE uplink, and 9.3 Gbps over-the-air speed.

Technical Specifications

Mechanical

Dimensions O206 x 46 mm (O8.1 x 1.8")

Weight 680 g (1.5 lb)

Enclosure materials Polycarbonate, metal

Mount material Mounting bracket: stainless steel (SUS304)

Backing plate: galvanized steel (SGCC)

Hardware

Networking interface (1) 2.5 GbE RJ45 port

Management interface Ethernet

Power method PoE+

Power supply UniFi PoE switch

Supported voltage range 44—57V DC

Max. power consumption 21W

Max. TX power

2.4 GHz

5 GHz

6 GHz

22 dBm

26 dBm

23 dBm

MIMO

2.4 GHz

5 GHz

6 GHz

2 x 2

2 x 2

2 x 2

Throughput rate

2.4 GHz

5 GHz

6 GHz

688 Mbps

2882 Mbps

5765 Mbps

Antenna gain

2.4 GHz

5 GHz

6 GHz

4 dBi

6 dBi

5.8 dBi

LEDs White/blue

Button Factory reset

Mounting Wall/ceiling (Included)

Operating temperature -30 to 60° C (-22 to 140° F)

Operating humidity 5 to 95% noncondensing

Certifications CE, FCC, IC

Software

WiFi standards 802.11a/b/g/n/ac/ax/be

Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)

BSSID 8 per radio

VLAN 802.1Q

Advanced QoS Per-user rate limiting

Guest traffic isolation Supported

Concurrent clients 300+

Supported Data Rates

802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b 1, 2, 5.5, 11 Mbps

802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)

802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)

802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)

Application Requirements

UniFi Network Version 8.0.7 and later

UniFi OS Version 3.2 and later
