Ubiquiti Unifi Express, Cloud Gateway and WiFi 6 access point

Powerfully compact UniFi Cloud Gateway and WiFi 6 access point that runs UniFi Network. Powers an entire network or simply meshes as an access point.

Built-in WiF6 (2x2 MIMO)



140 m2 (1,500 ft2) single-unit coverage



60+ connected WiFi devices



(1) GbE RJ45 WAN port



(1) GbE RJ45 LAN port to extend network



0.96" LCM status display



Technical specification:



Mechanical

Dimensions 98 x 98 x 30 mm (3.6 x 3.6 x 1.2")

Weight 302 g (10.7 oz)

Enclosure material Polycarbonate

Hardware

Networking interface (1) GbE RJ45 WAN port

(1) GbE RJ45 LAN port

Management interface Ethernet

Bluetooth

Power method USB type C (5V DC/3A)

Max. power consumption 10W

Max. WiFi TX power

2.4 GHz

5 GHz

22 dBm

25 dBm

MIMO

2.4 GHz

5 GHz

2 x 2 (DL/UL MU-MIMO)

2 x 2 (DL/UL MU-MIMO)

Throughput rate

2.4 GHz

5 GHz

573.5 Mbps

2.4 Gbps

Antenna gain

2.4 GHz

5 GHz

4 dBi

5.15 dBi

Antennas (2) Internal 2.4G/5G WiFi dual-band antenna

(1) Internal 2.4G single-band BT antenna

LCM display 0.96" status display

Button Factory reset

Operating temperature -10 to 45° C (14 to 113° F)

Operating humidity 5 to 95% noncondensing

Certifications CE, FCC, IC

Software

WiFi standards 802.11a/b/g

WiFi 4/WiFi 5/WiFi 6

Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

BSSID 8 per radio

VLAN 802.1Q

Advanced QoS Per-user rate limiting

Guest traffic isolation Supported

Concurrent clients 60+

Zero wait DFS Yes

Supported Data Rates

802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b 1, 2, 5.5, 11 Mbps

802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (WiFi 4) 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)

802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/1
