Zyxel XS3800-28, 28-port 10GbE L2+ Switch, MultiGig, 12x 10G Copper, 8x 10G dual pers., 8x 10G SFP+. Dual PSU
| Kód tovaru: | 111910 |
|---|---|
| Výrobca: | ZYXEL |
| PN kód: | XS3800-28-ZZ0101F |
| EAN kód: | 4718937600960 |
| Záruka: | 2147483647 dní |
| Dostupnosť: | nie je skladom |
Port Density
Total port count 28
100M/1G/2.5G/5G/10G Ethernet (RJ-45) 4
Multi-Gigabit combo (100M/1G/2.5G/5G/10G) RJ-45/(1G/10G) SFP+ 8
1G/10G SFP+ 16
Performance
Switching capacity (Gbps) 560
Forwarding rate (Mpps) 416
Packet buffer (byte) 4 MB
MAC address table 32 K
L3 forwarding table Max. 4 K IPv4 entries
Max. 2 K IPv6 entries
Routing table 1K
IP interface 128
Flash/RAM 64 MB/8 GB
Power
Input Dual power
100 - 240 V AC, 50/60 Hz
Max. power consumption (watt) 86.97
Physical Specifications
Dimensions (WxDxH)(mm/in.) 441 x 360 x 44/17.36 x 14.17 x 1.73
Weight (kg/lb.) 4.81/10.6
Included accessories
Power cord
Rack mounting kit
Environmental Specifications
Operating Temperature 0°C to 50°C/32°F to 122°F
Humidity 10% to 95% (non-condensing)
Storage Temperature -40°C to 70°C/-40°F to 185°F
Humidity 10% to 95% (non-condensing)
MTBF (hr) 656,274.78
Heat dissipation (BTU/hr) 296.57
Acoustic noise @ 25°C (dBA) 58.2
Parametre
| Hĺbka jedn. balenie | 13.4 |
| Hmotnosť jedn. balenie | 7.404 |
| Počet kusov jedn. balenie | 1 |
| Rozmer xyz jedn. balenie | 59.6x53.1x13.4 |
| Šírka jedn. balenie | 59.6 |
| Typ balenia jedn. balenie | Balitelné |
| Výška jedn. balenie | 53.1 |
| Hmotnosť kartónu | 23.560 |
| Typ obalu kartón | Expedovatelné |
| Počet kusov v kartóne | 3 |
| Rozmer xyz kartónu | 61x55x42 |
| Typ balenia kartónu | Balitelné |
| Počet LAN portov | 28 |
| Prevedenie switcha | Do racku |
| Fanless switch | Ne |
| Obsahuje switch | Ano |
| Rýchlosť LAN max. | 10 Gbps |
| Optika | Ano |
| Počet SFP+ portov | 24 |
| Management | Managed switch |
